Product Details
The Mean Well XLG-200-24 200W LED Power Supply is a professional-grade constant power mode driver designed for high-performance LED lighting applications. Delivering a stable 24V DC output at 8.3A, it provides reliable and efficient power for both indoor and outdoor installations. With a wide universal AC input range of 100–305VAC and efficiency up to 94%, this driver supports global projects while reducing energy use. Its IP67-rated aluminum housing protects against dust, water, and harsh weather, making it ideal for rugged environments. Engineered with advanced surge protection and built-in safeguards against overvoltage, overload, and overheating, the XLG-200-24 ensures long-term safety and durability. The integrated 3-in-1 dimming function allows flexible brightness control for diverse lighting scenarios. Backed by a 5-year warranty, it is well-suited for street lighting, signage, architectural, industrial, and horticultural projects.
Key Features
- 200W constant power LED driver with 24V DC / 8.3A output
- Wide AC input range: 100–305VAC for global installations
- High efficiency up to 94% for energy savings
- IP67-rated metal housing for waterproof and dustproof protection
- Advanced surge protection: 6KV/4KV with over voltage, over load, and over temperature safeguards
- 3-in-1 dimming compatibility for flexible brightness control
- 5-year warranty for long-term reliability
Recommended Applications
- Street and flood lighting: reliable, weather-resistant driver for municipal projects
- Architectural and façade lighting: stable brightness for commercial and decorative environments
- LED signage and displays: efficient, long-lasting power for advertising solutions
- Horticultural and greenhouse lighting: dependable driver for controlled plant growth
- Industrial and commercial lighting: robust solution for bay lights, stage, and warehouse installations
 |
 |
Specifications
| XLG-100W-12V | XLG-150W-12V | XLG-100W-24V | XLG-150W-24V | XLG-200W-24V | |
| Input Voltage | 100 ~ 305VAC | ||||
| Input AC Current(Max.) | 1.1 A | 1.8 A | 1.1 A | 1.8 A | 2.2 A |
| Output Voltage | 12 VDC | 24 VDC | 12 VDC | 24 VDC | 24 VDC |
| Output Power | 96 W | 150 W | 96 W | 150 W | 199.2 W |
| Output Current | 8 A | 12.5 A | 4 A | 6.25 A | 8.3 A |
| Certificate | UL, CSA, EN | ||||
| Safety Standards | UL 8750, UL 879 | ||||
| Warranty | 5 Years | ||||
| Protections | Over Current, Short Circuit, Over Voltage, Over Temperature | ||||
| Waterproof Performance | IP67 | ||||
