Product Details
The Mean Well XLG-150-12 150W LED Power Supply is a high-performance driver designed for professional LED lighting systems requiring durability, efficiency, and safety. Operating in constant power mode, it delivers a stable 12V DC output at up to 12.5A, ensuring precise and consistent illumination. With a wide AC input range of 100–305VAC, this driver is globally compatible and supports both residential and commercial applications. Built for demanding environments, its IP67-rated metal housing offers complete protection against water, dust, and harsh weather, making it ideal for indoor and outdoor projects. Offering high efficiency and superior heat dissipation, the XLG-150-12 ensures long-term reliability and energy savings. It features advanced surge protection and built-in safety functions for secure operation. Supporting 3-in-1 dimming, this LED driver is perfect for street lighting, floodlighting, horticulture, signage, and architectural projects.
Key Features
- 150W constant power LED driver with 12V DC / 12.5A output
- Wide 100–305VAC universal input for global applications
- High efficiency with excellent heat dissipation
- IP67-rated metal housing for waterproof, dustproof, and outdoor durability
- Built-in protection with surge resistance up to 6KV/4KV
- 3-in-1 dimming support for versatile lighting control
Recommended Applications
- Street and flood lighting: reliable and efficient driver for municipal projects
- Architectural and façade lighting: stable brightness with long-term safety
- LED signage and display boards: 24/7 dependable power for advertising
- Horticultural and greenhouse lighting: controlled environment performance
- Industrial and commercial bay lights / stage lighting: robust solution for demanding installations
 |
 |
Specifications
| XLG-100W-12V | XLG-150W-12V | XLG-100W-24V | XLG-150W-24V | XLG-200W-24V | |
| Input Voltage | 100 ~ 305VAC | ||||
| Input AC Current(Max.) | 1.1 A | 1.8 A | 1.1 A | 1.8 A | 2.2 A |
| Output Voltage | 12 VDC | 24 VDC | 12 VDC | 24 VDC | 24 VDC |
| Output Power | 96 W | 150 W | 96 W | 150 W | 199.2 W |
| Output Current | 8 A | 12.5 A | 4 A | 6.25 A | 8.3 A |
| Certificate | UL, CSA, EN | ||||
| Safety Standards | UL 8750, UL 879 | ||||
| Warranty | 5 Years | ||||
| Protections | Over Current, Short Circuit, Over Voltage, Over Temperature | ||||
| Waterproof Performance | IP67 | ||||
