Product Details
The 8W Single Output Switching LED Power Supply delivers stable, efficient, and reliable performance for powering LED lighting systems. Utilizing advanced switching technology, it provides consistent voltage and current output, protecting LEDs from surges and fluctuations while extending their service life. Designed with a compact and lightweight housing, it is the ideal choice for installations where space is limited but dependability is essential. With high efficiency, minimal standby power consumption, and excellent heat dissipation, this LED driver ensures long-lasting, safe operation. Equipped with protections against short circuit, overload, and overvoltage, the Mean Well 8W LED power supply is trusted globally for use in commercial, residential, and architectural lighting projects.
Key Features
- 8W single output switching LED driver
- Compact size with energy-efficient performance
- Built-in protections: short circuit, overload, overvoltage
- Designed for durable and stable LED operation
- IP30-rated enclosure
Recommended Applications
- Residential & commercial LED lighting: ensures stable operation
- LED signboards & digital displays: supports reliability
- Architectural illumination: consistent brightness and efficiency
- Retail & hospitality environments: safe, efficient LED driver solution
- Custom LED installations: versatile driver for compact projects
![]() |
![]() |
Specifications
APV-8W-12V | APV-35W-12V | APV-8W-24V | APV-35W-24V | |
Input Voltage | 90 ~ 264VAC | |||
Input AC Current(Max.) | 0.3 A | 0.75 A | 0.3 A | 0.75 A |
Output Voltage | 12 VDC | 24 VDC | 12 VDC | 24 VDC |
Output Power | 8 W | 36 W | 8 W | 36 W |
Output Current | 0.67 A | 3 A | 0.34 A | 1.5 A |
Certificate | UL, CSA, EN | |||
Safety Standards | UL 8750 | |||
Warranty | 2 Years | |||
Protections | Over Load, Short Circuit, Over Voltage | |||
Waterproof Performance | IP30 | IP42 |
Documents
