The G-24060-DWL is a high-efficiency 60W 24V dimmable LED driver, designed for professional electrical installations in commercial, industrial, and residential projects. Featuring a universal AC input (100-277VAC), this driver ensures reliable performance across various voltage conditions. With a fully waterproof (IP66) compact housing, it is ideal for both indoor and outdoor applications. Its 5-in-1 dimming capability (Triac, 0-10V, PWM, ELV ) allows for seamless, flicker-free dimming. UL, cUL listed, Class 2, Type HL rated, and FCC compliant, this driver meets strict safety and performance standards for electrical engineering projects. Backed by a 5-year warranty, it guarantees long-term reliability and compliance with T24 and JA8 regulations.
Key Features
Universal Input Voltage: 100-277VAC for broad installation compatibility.
Full Dimming Control: 0-100% smooth dimming with Triac, 0-10V, PWM, ELV.
Compact & Waterproof Design: IP66-rated housing for wet and damp locations.
Certified for Professional Use: UL, cUL listed, Class 2, Type HL rated, FCC compliant.
Energy Efficient & Stable: Delivers flicker-free 24V DC output for LED lighting systems.
5-Year Warranty: Ensures durability and performance for long-term projects.
Recommended Applications
Commercial & Industrial Lighting – Suitable for office buildings, warehouses, and public spaces.
Architectural & Cove Lighting – Provides smooth, adjustable brightness for high-end designs.
Exterior & Landscape Lighting – Withstands outdoor conditions with its IP66-rated housing.
Retail & Display Lighting – Ensures high-quality illumination for showrooms and displays.
Smart Home & Automation – Fully compatible with leading dimming and control systems.
 |
 |
| Model | Input Voltage Range | Output Voltage | Max Output Current | Max Output Power | Weight | Protection Rating | Output Type | Standards | Dimming Method |
|---|---|---|---|---|---|---|---|---|---|
| G-24060-DWL | 100-277V AC | 24V ±0.5V | 2.5A | 60W | 0.35KG | Dry, Damp & Wet | 20kHz PWM | UL listed, Meets T24, JA8 Test | Triac/Phase & 0/1-10V 5 in 1 |
| G-24100-DWL | 100-277V AC | 24V ±0.5V | 4.16A | 100W | 0.48KG | Dry, Damp & Wet | 20kHz PWM | UL listed, Meets T24, JA8 Test | Triac/Phase & 0/1-10V 5 in 1 |
| G-24150-DWL | 110-277V AC | 24V ±0.5V | 6.25A | 150W | 0.50KG | Dry, Damp & Wet | 20kHz PWM | UL listed, Meets T24, JA8 Test | Triac/Phase & 0/1-10V 5 in 1 |
| G-24150-DWS | 110-277V AC | 24V ±0.5V | 6.25A | 150W | 0.35KG | Dry & Damp | 20kHz PWM | UL listed, Meets T24, JA8 Test | Triac/Phase & 0/1-10V 5 in 1 |
| G-24150-DWL | 110-277V AC | 24V ±0.5V | 6.25A | 150W | 0.50KG | Dry, Damp & Wet | 20kHz PWM | UL listed, Meets T24, JA8 Test | Triac/Phase & 0/1-10V 5 in 1 |
Frequently bought together:
 |
 |
 |
 |
| All LED Strip Light | All LED Controller | All LED Transformer | All Aluminum Channel |
Q&A:
How to select a dimmable transformer for LED lights?
The following factors needs to considered when selecting a dimmable transformer for LED lights: (1) Check compatibility with your specific LED lights; (2) Determine the dimming method (PWM or analog) and choose a transformer accordingly; (3) Consider the desired dimming range and ensure the transformer supports it; (4) Verify the transformer's load capacity meets or exceeds the total wattage of your LED lights; (5) Choose a reputable manufacturer for quality and reliability; (6) Ensure compatibility with your chosen dimmer switch or controller; (7) Look for relevant certifications and standards.
|
Instruction Video: GL LED 5-in-1 G-series Transformer Instruction Video: How to choose your correct transformer |
