The G-24100-DWL is a 100W 24V dimmable LED driver designed for professional lighting installations in commercial, industrial, and residential construction projects. It features a universal AC input (100-277V), ensuring compatibility with various electrical systems. With an IP66-rated waterproof housing, this compact and slim power supply is ideal for tight spaces and demanding environments. Its 5-in-1 dimming technology (Triac, 0-10V, PWM, ELV) delivers smooth, flicker-free dimming for energy-efficient LED lighting solutions. Certified to UL, T24, and JA8 standards, this driver ensures safety, performance, and compliance with modern construction regulations.
Key Features
100-277V AC Input – Wide voltage range for diverse installations.
Smooth 5-in-1 Dimming – Supports Triac, 0-10V, PWM, ELV dimming systems.
Compact & Waterproof – IP66-rated for wet, damp, and dry locations.
Stable 24V DC Output – Ensures flicker-free performance for LED lighting applications.
UL Listed & Code Compliant – Meets T24, JA8 test standards for building codes.
Energy-Efficient Design – Reduces heat dissipation and power consumption.
5-Year Warranty – Ensures long-term reliability and durability.
Recommended Applications
Commercial & Residential Construction – Ideal for office buildings, hotels, and multi-unit housing.
Architectural & Cove Lighting – Provides high-precision dimmable illumination.
Outdoor & Landscape Lighting – Weather-resistant for patios, gardens, and pathways.
Retail & Display Lighting – Enhances product visibility with consistent brightness control.
Smart Home & Automation – Compatible with advanced dimming and control systems.
 |
 |
| Model | Input Voltage Range | Output Voltage | Max Output Current | Max Output Power | Weight | Protection Rating | Output Type | Standards | Dimming Method |
|---|---|---|---|---|---|---|---|---|---|
| G-24060-DWL | 100-277V AC | 24V ±0.5V | 2.5A | 60W | 0.35KG | Dry, Damp & Wet | 20kHz PWM | UL listed, Meets T24, JA8 Test | Triac/Phase & 0/1-10V 5 in 1 |
| G-24100-DWL | 100-277V AC | 24V ±0.5V | 4.16A | 100W | 0.48KG | Dry, Damp & Wet | 20kHz PWM | UL listed, Meets T24, JA8 Test | Triac/Phase & 0/1-10V 5 in 1 |
| G-24150-DWL | 110-277V AC | 24V ±0.5V | 6.25A | 150W | 0.50KG | Dry, Damp & Wet | 20kHz PWM | UL listed, Meets T24, JA8 Test | Triac/Phase & 0/1-10V 5 in 1 |
| G-24150-DWS | 110-277V AC | 24V ±0.5V | 6.25A | 150W | 0.35KG | Dry & Damp | 20kHz PWM | UL listed, Meets T24, JA8 Test | Triac/Phase & 0/1-10V 5 in 1 |
| G-24150-DWL | 110-277V AC | 24V ±0.5V | 6.25A | 150W | 0.50KG | Dry, Damp & Wet | 20kHz PWM | UL listed, Meets T24, JA8 Test | Triac/Phase & 0/1-10V 5 in 1 |
Frequently bought together:
 |
 |
 |
 |
| All LED Strip Light | All LED Controller | All LED Transformer | All Aluminum Channel |
Q&A:
How to select a dimmable transformer for LED lights?
The following factors needs to considered when selecting a dimmable transformer for LED lights: (1) Check compatibility with your specific LED lights; (2) Determine the dimming method (PWM or analog) and choose a transformer accordingly; (3) Consider the desired dimming range and ensure the transformer supports it; (4) Verify the transformer's load capacity meets or exceeds the total wattage of your LED lights; (5) Choose a reputable manufacturer for quality and reliability; (6) Ensure compatibility with your chosen dimmer switch or controller; (7) Look for relevant certifications and standards.
|
Instruction Video: GL LED 5-in-1 G-series Transformer Instruction Video: How to choose your correct transformer |
