Product Details
The 5-in-1 Dimmable LED Driver 60W 24V (GLG-DWJ Series) is a professional-grade constant voltage power supply designed for maximum flexibility and compatibility. Supporting five dimming methods—0-10V, 1-10V, 10V PWM, potentiometer, TRIAC (forward phase), ELV (reverse phase), and MLV (magnetic low voltage)—this driver delivers flicker-free performance across a wide range of control systems. With a 60W / 24V DC output, IP66-rated waterproof housing, UL Class 2 and Type HL certifications, and a 5-year warranty, it is built to perform in both residential and commercial projects.
Key Features
- 5-in-1 Dimming – Compatible with 0-10V, 1-10V, 10V PWM, potentiometer, TRIAC, ELV, and MLV dimming methods.
- 60W / 24V DC Constant Voltage – Provides 2.5A stable output for LED strips and fixtures.
- Flicker-Free Performance – High-frequency PWM (≥20 kHz) ensures smooth 0–100% dimming.
- Durable IP66 Housing – Waterproof and dustproof design suitable for indoor and outdoor use.
- Certified Safety – UL8750, Class 2 unit, Type HL rated; built-in overload, short circuit, and thermal protection.
- Reliable Efficiency – Up to 88% efficiency, low THD, and power factor up to 0.99 for energy savings.
Recommended Applications
- Architectural Lighting – Flexible dimming for coves, facades, and accent lighting.
- Residential LED Projects – Smooth brightness control for kitchens, living rooms, and home theaters.
- Retail & Display Lighting – Precise dimming for shelves, showcases, and product highlights.
- Hospitality Spaces – Reliable dimming for hotels, restaurants, and lounges.
- Large-Scale Installations – Strong compatibility with commercial dimmers for scalable projects.
 |
 |
Specifications
| Type | GLG-24060-DWJ | GLG-24096-DWJ | GLG-C24192-DWJ | GLG-C24288-DWJ | GLG-24060-DWL | GLG-24100-DWL | GLG-24150-DWL/DWS | GLG-24150-DWJ | GLG-24200-DWJ | GLG-24300-DWJ | GLG-24600-DWJ |
| Input Voltage | 100-277VAC | 110-277VAC | |||||||||
| Input AC Current (Max.) | 0.5A@100VAC | 1.3A@100VAC | 2.3A | 3.4A | 1.3A@100VAC | 1.3A@100VAC | 1.8A@100VAC | 1.8A@100VAC | 2.3A@100VAC | 3.4A@100VAC | 5.9A@100VAC |
| Output Voltage | 24VDC | ||||||||||
| Output Power | 60W | 96W | 96W*2 = 192W | 96W*3 = 288W | 60W | 100W | 150W | 150W | 200W | 300W | 600W |
| Output Current | 2.5A | 4A | 4A*2 | 4A*3 | 4A | 4.17A | 6.2A | 6.25A | 8.33A | 12.5A | 25A |
| Certificate | 150W, 200W, 300W, 600W: UL, Type HL rated; 60W, 96W, 192W, 288W: Class2, UL, Type HL rated, ROHS; |
||||||||||
| Safety Standards | UL8750 | ||||||||||
| Warranty | 5 years | ||||||||||
| Dimming Range | 0-100% | ||||||||||
| Protections | Short Circuit / Over Loading / Over Temperature | ||||||||||
| Work Environment | Dry / Damp / Wet Location | ||||||||||
| Frequency Range | 20K HZ | ||||||||||
| Dimming Method |
|
||||||||||
Documents
LED Dimmable Driver - 5 in 1 dimming_Specification
Technical Tips & Guidance
Step-by-Step: How to Choose the Right Power Supply for Your LED Setup
The Complete Guide to Power Supply Protection – Why GLG Drivers Are the Safe and Reliable Choice for LED Systems
Which LED Dimmable Power Supply is Right for You? GLE series vs. GLG series.
Frequently bought together
 |
 |
 |
 |
| All LED Strip Light | All LED Controller | All LED Transformer | All Aluminum Channel |
Instruction Video
5 in 1 Transformer Introduction |
