Product Details
This product is made of pure copper wire, which has excellent conductivity and high efficiency in transmitting current. It has low resistance and low voltage loss, and is suitable for long-distance power transmission. It has good heat dissipation and is durable. It is not easy to overheat or fuse, and has high safety. It is suitable for home/commercial wiring, industrial control systems, automotive circuits and other environments with high requirements and strong safety.
DC 4 Conductor Wire for low voltage installations. Ideal for LED RGB strip lights.
Specifications
| Conductor Type | 4 Conductor (Red & Green & Blue & Clear) |
| Material | Pure copper wire with durable PVC insulation |
| Cross Section | 20 AWG |
| Stranding | 17 strands x 0.16 mm² |
| Round Wire | Yes |
| Working Temperature | 176 °F |
| Voltage Rating | Low voltage DC applications |
| Certification | UL Listed |
| Length Options | 50ft |
| Color | Red & Green & Blue & Silver |
| Using Environment | Indoor |
Features
- Pure Copper Conductor: Excellent electrical conductivity with low resistance and minimal voltage drop.
- High Safety: Stable current flow, not easy to overheat or fuse.
- Durable Insulation: Flame-retardant PVC jacket ensures longevity and protection.
- Efficient Heat Dissipation: Prevents overheating in continuous use.
- Flexible Handling: Easy to strip, cut, and connect for versatile wiring applications.
Applications
The 22AWG 4 Conductor Wire is ideal for RGB low voltage and safe power transmission scenarios, including:
- DC connections for LED RGB strip lights
- Home and commercial wiring projects
- Industrial control systems and automation
- Automotive circuits, trailers, and accessories
- DIY electronics and power supply connections
