Product Details
The Mean Well HLG-320H-24 320W LED Power Supply is a premium-grade constant voltage and constant current driver engineered for professional LED lighting systems. Delivering a stable 24V DC output at up to 13.34A, it ensures reliable power for demanding indoor and outdoor applications. With a wide input range of 90–305VAC and efficiency up to 94%, this driver maximizes energy savings and long-term performance. Its IP65-rated aluminum housing provides protection against harsh weather, making it ideal for rugged environments. Built-in active PFC, superior heat dissipation, and fanless design allow quiet, maintenance-free operation even at case temperatures between -40°C and +90°C. Equipped with 3-in-1 dimming options for design flexibility, the HLG-320H-24 is backed by a 7-year warranty. Perfect for street lighting, high-bay lighting, signage, horticulture, and architectural illumination.
Key Features
- 320W constant voltage + constant current LED driver (24V DC / 13.34A output)
- Universal input range 90–305VAC with active PFC
- Up to 94% efficiency for energy-saving performance
- IP65-rated metal housing for outdoor and indoor durability
- Built-in protections: short circuit, over voltage, over load, over temperature
- 3-in-1 dimming options for flexible brightness control
- 7-year warranty for long-term reliability
Recommended Applications
- LED street lighting – efficient, weather-resistant driver for municipal projects
- High-bay and industrial lighting – ensures consistent brightness in warehouses and factories
- LED signage and displays – dependable 24/7 power for commercial advertising
- Horticultural lighting systems – reliable driver for grow lights in controlled environments
- Architectural and decorative lighting – enhances facades, parking lots, and outdoor installations
 |
 |
Specifications
| HLG-320W-24V | HLG-600W-24V | |
| Input Voltage | 90-305 VAC | |
| Input AC Current(Max.) | 3.5 A | 7 A |
| Output Voltage | 24 VDC | |
| Output Power | 320.16 W | 600 W |
| Output Current | 13.34 A | 25 A |
| Certificate | UL, CSA, EN | |
| Safety Standards | UL 8750 | |
| Warranty | 7 Years | |
| Protections | Over Current, Short Circuit, Over Temp, Over Voltage | |
| Waterproof Performance | IP65 | |
